Channel baling press HSM VK 1210 For industrial applications with small material loads -... more
Channel baling press HSM VK 1210
For industrial applications with small material loads - Troughput up to approx. 117 m³/h
Particularly suitable for cardboard, plastic film and PET bottles
Loading aperture of 1000 mm suitable for larger material pieces and higher throughput rates
Available as an option with manual strapping
Very low space requirement thanks to compact and sturdy design
Integration into automated industrial production processes
Suitable for continuous loading with conveyor belt, air feeding or similar
Compact bale dimensions
Control of the pressing process via light barrier
Operating side can be selected
Technical data "HSM VK 1210"
| Order number: | 6617001 |
| Pressing power: | 159 kN |
| Specific pressing power: | 42,4 N/cm² |
| Driving power: | 9,2 kW |
| Voltage / Frequency: | 400 V / 50 Hz |
| Cycle time when idling vacío: | 11,5 s |
| Volume throughput in idle operation (theor.): | 117 m³/h |
| Volume throughput at 50kg/m³ (theor.): | 5.85 t/h |
| Loading aperture width x Loading aperture length: | 670 x 1000 mm |
| Bale width x Bale height x Bale length: | 750 x 500 x 600-1200 mm |
| Length x Width x Height: | 5940 x 2700 x 1940 mm |
| Weight: | 3,8 t |
| Type of consumables: | Wire |
| Press material: | Plastic film, Mixed paper, Cardboard, Punch waste/residue, PET beverage and aluminium cans, soft packaging, PET |
